Bending Beam

  • Bending beam load cells in stainless steel.

    A universal load cell for middle size industrial applications, measuring the bending. The compact construction easies mounting. Transverse forces and torque effect the measurement.

    Complete platforms including load cells are available as well.



  • STAINLESS STEEL

    Product Name

    Type 300

    Ideal for multiple load cells, platforms and general purpose application.

    • hygienic
    • 5 – 500 kg range
    • accuracy class C3/C6
    • protection class IP68/IP69K

    Download Leaflet


    STAINLESS STEEL

    Product Name

    Type 340

    Ideal for multiple load cells, platforms and general purpose application.

    • hygienic
    • 15 – 1500 kg range
    • accuracy class C3
    • protection class IP68

    Download Leaflet


    STAINLESS STEEL

    Product Name

    Type 355

    Ideal for multiple load cells, platforms and general purpose applications.

    • hygienic
    • 5 – 500 kg range
    • accuracy class up to C4
    • protection class IP68

    Download Leaflet


    STAINLESS STEEL

    Product Name

    Type SB6

    Ideal for multiple load cells, platforms and general purpose applications.

    • hygienic
    • 20 - 200 kg range
    • accuracy class up to C4
    • protection class IP68

    Download Leaflet


    STAINLESS STEEL

    Product Name

    Type SB8

    Ideal for multiple load cells, platforms and general purpose applications.

    • hygienic
    • 10 - 500 kg range
    • accuracy class up to C3
    • protection class IP68

    Download Leaflet

     ↑ Back to top


    STAINLESS STEEL

    Product Name

    Type SHBxR

    Ideal for multiple load cells, platforms and general purpose applications.

    • hygienic
    • 5- 500 kg range
    • accuracy class up to C4
    • protection class IP66 and IP68

    Download Leaflet
